Stanley 709 FSTANLEY 709 F, TIG rod is an extremely low carbon stainless steel Alloy with extra high molybdenum content added to provide superior corrosion resistance.
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
STANLEY 711 is used for welding materials of similar chemical composition which are used A special STANLEY 709 F, TIG alloy coated with our unique Vari-Flow fluxing system
• A very special TIG wire that eliminates the expense and wasted time associated with purging pipes with inert backing gasses
• Easy to handle 18 inch ( 450mm ) length works in multiple positions without having to bend the wire. |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value Up to:
Tensile Strength 80,000 Psi ( 550 MPa )
Yield Strength 56,000 Psi ( 390 MPa )
Elongation 42%
Impact Energy 40J: -157ºF ( -105ºC )
Hardness Brinell 209, Rockwell B96
APPLICATIONS :
STANLEY 709 F, TIG rod is an extremely low carbon stainless steel Alloy with extra high molybdenum content added to provide superior corrosion resistance. It is especially well suited for welding stainless steel pipe wherever a backing ring or a purge gas is required in order to provide impurity free weldments. This is necessary during stainless steel pipe welding in the chemical and petro-chemical industries.
MICROSTRUCTURE :
Austenite with 3 – 9 % ferrite. Tipical ferrite number is 6.
RECOMMENDED CURRENT :
DC Straight (-)
WELDING POSITIONS :
Flat, Horizontal, Vertical up
WELDING TECHNIQUES :
Clean weld surface carefully to remove all scale and corrosion. Sections over 3 mm should be beveled to permit complete penetration. Clean joint surface using a stainless steel brush. Use DC - ( straight polarity ), 20 % thoriated tungsten electrode. |
|
