Stanley 711STANLEY 711 is used for welding materials of similar chemical composition which are used forfabrication of equipment and vessels for handling of sulfuric acid and chloride containing media.
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
| STANLEY 711 is used for welding materials of similar chemical composition which are used forfabrication of equipment and vessels for handling of sulfuric acid and chloride containing media. This filler metal may also find applications for joining type 317L material whereimproved corrosion resistance in specific media is needed. In order to reduce the propensityfor fissuring and hot cracking, the low melting constituents such as carbon, silicon, and phosphorus are controlled to lower levels in this alloy. |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value Up to:
Tensile Strength 88,000 Psi ( 607 MPa )
Yield Strength 65,000 Psi ( 452 MPa )
Elongation 37%
RECOMMENDED CURRENT :
DC Reverse ( + ) or AC
WELDING POSITIONS :
Flat, Horizontal, Vertical up, Overhead.
WELDING TECHNIQUES :
Remove all surface contamination. Weld with a short arc and use stringer beads. Keep heat input to a minimum. |
|
