Stanley 801Ideally suited for difficult maintenance repairs. Easily welds steels that have been galvanized, painted, rusted, or otherwise contaminated in service. Misaligned parts or difficult to access areas are also easily remedied with this electrode.
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Nickel bearing low hydrogen designed for joining low alloy steels requiring high elongation combined with excellent low temperature impact values.
• Phenomenal combination of physical properties.
• Excellent welding characteristics and deposit appearance.
• Extra low moisture content is below 14%. |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value Up to:
Tensile Strength 92,000 Psi ( 670 MPa )
Yield Strength 76,000 Psi ( 550 MPa )
Elongation 29%
Impact Energy 100J: -76ºF ( -60ºC )
90J: -103ºF ( -75ºC )
35J: -148ºF ( -100ºC )
APPLICATIONS :
Ideally suited for difficult maintenance repairs. Easily welds steels that have been galvanized, painted, rusted, or otherwise contaminated in service. Misaligned parts or
difficult to access areas are also easily remedied with this electrode.
RECOMMENDED CURRENT :
DC Reverse (+), Straight (-) or AC
WELDING POSITIONS :
Flat, Vertical up, Vertical down, Horizontal, Overhead.
WELDING TECHNIQUES :
Remove all surface contaminants. Maintain a short arc gap and use a stringer or slight weave technique. Chip slag thoroughly between passes.
|
|
