Stanley 802For joining common steels where extra strength is required in the weld. Exceptional where vertical welds have to be made.
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Totally unique "High Tensile Mild Steel" electrode that excels at vertical welding.
• Easy to use in all positions.
• Extra high tensile strength 97,000 psi ( 705 MPa ).
• Special violet colored flux establishes immediate recognition. |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value Up to:
Tensile Strength 97,000 Psi ( 705 MPa )
Yield Strength 78,500 Psi ( 565 MPa )
Elongation 17%
APPLICATIONS :
For joining common steels where extra strength is required in the weld. Exceptional where
vertical welds have to be made.
RECOMMENDED CURRENT :
DC Reverse (+) or AC
WELDING POSITIONS :
Flat, Vertical up, Vertical down, Horizontal, Overhead.
WELDING TECHNIQUES :
Hold a very short arc. In the vertical position, electrode can actually be dragged. |
|
