All position welding of fine grained unalloyed structural and construction grade steels witha carbon content of up to .4%.
Overview
Specifications
Email to a Friend
New Technology - Very unique "Double Coated" low hydrogen electrode excels at AC welding.
• Unique "Double" flux coating separates those flux constituents which impair arc stability to the outside of the flux coating.
• The only "Low Hydrogen" electrode that can easily be used on low open circuit voltage AC farm type welders.
• The unusually stable arc makes this electrode ideally suited for root passes and positional welding.
Overview
Specifications
Email to a Friend
APPLICATIONS :
All position welding of fine grained unalloyed structural and construction
grade steels witha carbon content of up to .4%.
MICROSTRUCTURE :
In the stress-relieved condition the microstructure consists of acicular ferrite with some tempered bainite.
RECOMMENDED CURRENT :
DC Reverse (+) or AC
WELDING POSITIONS :
Flat, Horizontal, Vertical up, Overhead.
WELDING TECHNIQUES :
Clean areas to be joined. Initiate arc and use conventional "stringer weld" technique. Electrode can be dragged.
