Stanley 55 TIGLow Melting Aluminum Solder for Joining Aluminum to Itself and Other Metals
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Strong low temperature solder for joining aluminum to other metals
- Excellent wetting and flow characteristics on almost all ferrous and non-ferrous metals.
- Retains high strength even at temperatures up to 350 F (175 C).
- Better corrosion resistance and higher strength than ordinary soft solders.
|
|
Overview |
|
Specifications |
|
Email to a Friend |
|
With a lower bonding temperature than silver brazing alloys, it is ideal as an intermediate alloy for joining.
Excellent for low temperature joints on:
- Aluminum tube, copper tube, and refrigeration and air conditioning units
- Aluminum radiators
- Sheet metal work
- Manufacturing and repair of instruments
- Zinc base die casting
- Joining of dissimilar metals
- Can also be used on anodized aluminum
TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
Tensile strength
Electrical Conductivity
Corrosion Resistance
|
Maximum Value Up to:
20,000 psi (145 N/mm2)
Good Good
|
Soldering Techniques: Joint area should be thoroughly cleaned. Best results are obtained when maintaining a joint clearance of no more than .006". The entire joint area should be completely covered with 5140 flux. Heat part indirectly with a soft flame being careful not to burn the flux. As soon as flux starts to bubble, dip solder into flux and transfer it to joint. Continue heating until solder flows through the entire joint. Allow to cool slowly. Flux residue can be removed with hot water and stiff brush. |
|
