Stanley 607High build-up electrode depositing weldmetal that resist extreme compressive stresses
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
High build-up electrode depositing weldmetal that resists extreme compressive stresses
- Very tough alloy for underlayments or medium hard tough overlays.
- Excellent machinability.
- Excels in vertical and horizontal position welding.
|
|
Overview |
|
Specifications |
|
Email to a Friend |
|
APPLICATIONS:
For underlayments on carbon and low alloy steels, also as a stand
alone overlay for medium hard tough build-ups on rails, shafts, etc.
MICROSTRUCTURE:
Martensite with some carbides.
FLUX COLOR: Grey
TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
H a r d n e s s |
Maximum Value Up to:
Rockwell C 25-27 Brinell 270 |
RECOMMENDED CURRENT: DC Reverse (+) or AC
RECOMMENDED AMPERAGE SETTINGS:
| Diameter (mm) |
1/8(3.25) |
5/32 (4.0) |
3/16 (5.0) |
| Minimum Amperage |
100 |
140 |
180 |
| Maximum Amperage |
140 |
180 |
230 |
WELDING POSITIONS: Flat, Horizontal, Vertical up
DEPOSITION RATES:
Diameter
(mm) |
Length
(mm) |
Weldmetal/
Electrode |
Electrodes per lb
(kg) of Weldmetal |
Arc Time of
Deposition
min/lb (kg) |
Amperage
Setting |
| 1/8 (3.25) |
18" (450) |
.77oz (22g) |
20 (44) |
21 (47) |
120 |
| 5/32 (4.0) |
18" (450) |
1.33oz (39g) |
12 (26) |
18 (39) |
160 |
| 3/16 (5.0) |
18" (450) |
2.34oz (65g) |
7 (15) |
13 (28) |
205 |
WELDING TECHNIQUES:
Weld in a stringer or 3 x weave fashion. When welding vertically use the "whip" technique.
ELECTRODE PACKAGING & DIMENSIONS:
| Diameter(mm) |
1/8 (3.25) |
5/32 (4.0) |
3/16 (5.0) |
| Length (mm) |
18" (450) |
18" (450) |
18" (450) |
| Electrodes / lb |
9 |
6 |
5 |
| Electrodes / kg |
21 |
14 |
11 |
|
|
